Tablet Zone 1/21

IS940.1

The 10.1-inch 5G Android tablet for data communication in the process industry and in automation integrates seamlessly into the existing system landscape with 4G/5G campus networks or Wi-Fi 6. It is equipped with a powerful, IIoT-optimised chipset from Qualcomm® Technologies, Inc. Other highlights of the robust and easy-to-handle tablet include a 16-pin ISM interface, 12-pin ISM interface for Docking Station, Wi-Fi 6, Bluetooth 5.2 and NFC support, a replaceable, long-lasting battery, freely programmable buttons and main and front cameras.

Mini Picture

Advantages

  • Android™ operating system
  • Processor with long-term support: Qualcomm® QCM6490 Octa Core
  • Large memory with 8 GB RAM, 128 GB internal memory expandable with microSD memory up to 128 GB
  • Clear 10.1" display with Corning® Gorilla® Glass 3rd generation
  • Replaceable, powerful battery
  • Camera on the front and back
  • Wireless communications such as Wi-Fi® , Bluetooth®, Near Field Communication (NFC), GPS, A-GPS, Glonass, A-Glonass, Beidou, Galileo
  • Programmable red key (e.g. for lone worker protection/SOS)
  • Additional programmable side buttons (assignable via "Button App")
  • Mounting VESA 100
  • Amplified loudspeaker for noisy work environments
  • Type of protection: IP68 waterproof/dustproof
  • MIL-STD-810H
  • Can be used from -20 °C to +55 °C

Technical features

Operating systemAndroid™ 13
ProcessorQualcomm® QCM6490 Octa Core
Memory8 GB RAM
128 GB internal memory
microSD to 128 GB
Frequencies4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 MFBI/B13/B14/B17/B20/B25/B26/B28A/B28B/B29/B30/B66/B71/B68
4G LTE-TDD: B38/B39/B40/B41/B42/B43/B48
5G NR: n1/n2/n3/n5/n7/n8/n12/n14/n20/n25/n28/n30/n38/n40/n41/n48/n66/n71/n77/n78/n79
DimensionsSize: 266,17 x 168,46 x 19,82 mm
Weight: 1059 g
Display10,1" (25,654 cm) Corning® Gorilla® Glass V3
usable with gloves
Battery8160 mAh, 3,7 V
replaceable
Camera50 MP AF rear
5 MP FF front
ConnectivityWi-Fi® 6: IEEE 802.11 a/b/g/n/ac/e/k/r/ax/v with hotspot
Bluetooth® 5.2
GPS, A-GPS, Glonass, Beidou, Galileo
Near Field Communication
Types of protectionIP68 dust-/waterproof
MIL-STD 810H
Usable from -20 °C to +55 °C

Further features

Verstärkter Lautsprecher
Amplified loudspeaker
Sensors
Accelerometer, Gyroscope, Light, Magnetic, Proximity, Pressure sensors
SIM cart
Dual-SIM (Nano-SIM + eSIM)
Ladeoptionen (Desktopcharger, Magnetic)
USB-C, Docking Station
Download datatsheet | pdf ▪ 204 KB

Approvals

ATEX (Europe)
ATEX (Europe)
approved
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135°C Db
IECEx (International)
IECEx (International)
approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
NEC500 (North America)
NEC500 (North America)
applied for
Class I Div. 1 Groups A, B, C, D, T4
Class II Div. 1 Groups E, F, G, T135 °C
Class III
IA (South Africa)
IA (South Africa)
approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
PCEC (China)
PCEC (China)
approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
INMETRO (Brazil)
INMETRO (Brazil)
approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db

Contents

Included
  • Tablet
  • Battery
  • Hand Strap
  • i.safe PROTECTOR 2.0
  • Power Adapter universal
  • Display Protection Foil
  • Screwdriver
  • Safety Instructions
Approved Accessories for IS940.1
Charging systems
IS-MC930.1 Multi Charger Set
IS-MC930.1 Multi Charger Set
Multi Charger for six devices. Size: 600 x 250 x 115 mm (L x W x H). Compatible for IS930.x, IS940.x, IS945.x and IS910.x.
IS-MC930.1 Multi Charger Set
Quick Start Manual IS-MC930.1
pdf
707 KB
Download
i.safe PROTECTOR 2.0
Charging systems
i.safe PROTECTOR 2.0 USB-C Cable
i.safe PROTECTOR 2.0
i.safe PROTECTOR 2.0 USB-C Cable
For safe charging of the device via the type USB-C port.
Leather Cases
Leather Case black IS940.x/IS945.x
Leather Case black IS940.x/IS945.x
Made of high quality leather, black. With adjustable Shoulder Strap and holder for a stylus. Suitable for the devices IS940.x and IS945.x.
Leather Cases
Leather Case yellow IS940.x/IS945.x
Leather Case yellow IS940.x/IS945.x
Made of high quality leather, yellow. With adjustable neck strap and holder for a stylus. Suitable for the devices IS940.x and IS945.x.
4 pont strap IS930
Leather Cases
Shoulder Strap 30 mm for Leather Case tablet
4 pont strap IS930
Shoulder Strap 30 mm for Leather Case tablet
Made of durable blended fabric, adjustable.
Tragegurt IS930
Leather Cases
4-point Harness System tablet
Tragegurt IS930
4-point Harness System tablet
The carrying strap system, made of Teflon impregnated Cordura®, is designed for use with the new Leather Cases of the IS910.x and IS930.x devices. It ensures safe carrying in front of the body and consists of an ergonomic back harness with extra large contact areas on the shoulders. The strap adjustment options allow the working height and angle of inclination to be adjusted as required.
IS-Stylus
Others
IS-Stylus Set
IS-Stylus
IS-Stylus Set
Stylus for operating touch screens. Made of metal with exchangeable rubber tip and plastic spiral cable. Stylus dimensions: 125 x 10 mm (L x ø); length of spiral cable: flexible from 24 to 70 cm.
Display protection foils
PanzerGlass™ IS940.x/IS945.x
PanzerGlass™ IS940.x/IS945.x
PanzerGlass® foil for an extended protection of the display. Suitable for the devices IS940.x and IS45.x.
Service
Warranty extension
Warranty extension
With our comprehensive warranty and service offer, you can protect yourself against additional service costs and receive years of safety and protection directly from the manufacturer. From the very first day, your equipment is protected against accidental damage and normal wear and tear. This reduces your total cost of ownership and benefit from the precision and functionality of our equipment for a long time.
Warranty extension
Product information warranty extension
English
pdf
211 KB
Download

DOWNLOADS

Datasheet IS940.1
English
pdf
204 KB
Download
Operating Manual IS940.1
pdf
5 MB
Download
Safety Instructions IS940.1
pdf
2 MB
Download
FCC Statement IS940.x
pdf
30 KB
Download
IC Statement IS940.x
pdf
40 KB
Download
ATEX IS940.1
English
pdf
1 MB
Download
IECEx IS940.1
pdf
1 MB
Download
IA Southern Afrika (MTEx) IS940.1-IS.945.1
pdf
166 KB
Download
Doc IS940.1
pdf
240 KB
Download
PCEC IS940.1 / IS945.1
pdf
198 KB
Download
INMETRO IS940.1 / IS945.1
pdf
305 KB
Download
