Add-on Zone 2/22

IS-TC1A.2

The thermal camera IS-TC1A.2, in combination with the industrial smartphone IS530.2 detects temperatures in the Ex-hazardous area from -40 °C to 330 °C in a matter of seconds via the Seek Thermal app (free download in Google Play Store). The thermal images and videos are processed and documented directly via the ISM interface of the IS530.2 smartphone.

Advantages

  • Direct data transfer via multifunctional (ISM) interface
  • Direct interface connection with the device, no Bluetooth® necessary
  • Capture, analyze and document thermal images
  • Power supply via the connected device, therefore no battery necessary

Technical features

Sensor resolution200 (h) x 150 (v)
30000 pixel
FixFocus
Digital zoom via App
Sensor sensitivity65 mK (typical)
Frame rate<9 Hz bis 32 Hz
Scene dynamic range-40 °C bis 330 °C
Temperature accuracy±7 °C and 7 % (at 5 °C to 140 °C)
±10 °C and 10 % (at 140 °C to 330 °C)
Field of view35° (HFOV)
26° (VFOV)
Detection rangeup to 300 m
Recognition rangeup to 75 m
Identification rangeup to 25 m
DimensionsWeight: 195 g
Types of protectionIP67
MIL-STD 810H
Usable from -10 °C to +60 °C

Further features

Ladeoptionen (Desktopcharger, Magnetic)
Power supply over the connected mobile device
Download datatsheet | pdf ▪ 1 MB

Approvals

ATEX (Europe)
ATEX (Europe)
approved
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc
IECEx (International)
IECEx (International)
approved
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
UKEX (United Kingdom)
UKEX (United Kingdom)
approved
II 3G Ex ic IIC T4 Gb
II 3D Ex ic IIIC T135°C Db
NEC500 (North America)
NEC500 (North America)
approved
Class I Div 2 Groups A, B, C, D, T4
Class II Div 2 Groups F, G , T135˚C
Class III Div 2

Contents

Included
  • Quick Start Manual
  • Safety Instructions
  • Thermal camera
